SEM Service SEM816D 175HP-190HP Big Bulldozer Track Type Bulldozer

  • 1 - 2 Sets
    $84,580.00
  • 3 - 9 Sets
    $83,580.00
  • >=10 Sets
    $80,000.00
Engine Brand:
WEICHAI
Power(W):
175
Lead Time:
Quantity(Sets) 1 - 1 >1
Est. Time(days) 30 Negotiable
Customization:
Graphic customization (Min. Order: 1 Sets)
Customized packaging (Min. Order: 1 Sets)

More

Customized logo (Min. Order: 1 Sets) Less
Report Suspicious Activity
Overview
Quick Details
Machine Weight:
17,230kg
Dimension(Long * Breadth * High):
6600*3164*3076 mm
Warranty:
1 year
Condition:
New
After-sales Service Provided:
Field installation, commissioning and training, Field maintenance and repair service
Place of Origin:
Shandong, China
Brand Name:
SEM
Moving Type:
Crawler Bulldozer
Applicable Industries:
Farms, Construction works , Energy & Mining, Food & Beverage Shops
Hydraulic Pump Brand:
Bosch Rexroth
Hydraulic Cylinder Brand:
SEM
Hydraulic Valve Brand:
SEM
UNIQUE SELLING POINT:
High operating efficiency
Product name:
SEM 816D
Engine Model:
Weichai WD10G178E25
Blade type:
SU and U Blade
Blade Width:
3140mm
Rated power:
160hp
Color:
Orange Etc
Blade Capacity:
4..3M3
Blade Height:
1240 mm
Max.Blade Digging Depth:
430 mm
Powertrain Type:
Electric control,Dual-path,Hydrostatic Drive
Supply Ability
Supply Ability:
2 Set/Sets per Month
Packaging & Delivery
Packaging Details
RORO
Port
Tianjin/Shanghai/Qingdao
Lead Time :
Quantity(Sets) 1 - 1 >1
Est. Time(days) 30 To be negotiated
Video Description
Product Description

The hydrostatic system on all SEM models delivers higher efficiency high reliablity and resistance to wear,and the planetary final drive design delicers incerased torque ratio for higher transmission efficiency and lower maintenance costs.Joystick controls provide comfortable,precise balde operation.Advanced structure welding techniques and stress analysis ensure durability and long life.

Member's Rights※
I.In 2019,All the SEM bulldozer have been upgraded to the latest models
SEM816D 816DLGP SEM822D SEM822DLGP(EURO III Engine Emission).
The factory will not produce SEM816 822 816LGP 822LGP in the future.


II.Our company has deep cooperation with sem's general agent. Customers can buy cheaper machines from us than other trade companies.

III.The bulldozer is new machine(not second hand machine and refurbished), 100% made in Cat-Sem(Qingzhou)factory, we can provide sem original parts to customers.

Detailed Images

Hydrostatic Drive System

1.Upgraded hydrostatic system not only leverages Cat automatic, dual path, hydrostatic drive with electronic control technology of the third generation TTT, but also increases efficiency and reliability.
2.Adopt Rexroth German new generation one case drive pump to combine control valve, track motor, simplified hose line design, continue to increase the reliability.
3.Integrated the hydrostatic oil tank and implement hydraulic oil tank to improve filtrated precision and cooling capability of hydraulic system, increasing reliability and reducing maintenance cost.

Comfortable Operation

Counter rotation-Tracks counter rotate to provide best in class maneuverability.
■ Powered turn-Machine maintains full power through turns to increase productivity.
■ Cruise control - Operators can retain previous speed settings which makes operation easily.
■ Multi-function joystick allows for counter-rotation, powered turn and cruise control.
■ Pilot joystick control provides comfortable precise blade operation.

Semi-Universal Blade

■ SU blade combines the excellent penetration of the S blade and the high production capacity of the U blade.
■ Designed for superior load retention and penetration in tightly packed materials.
■ L-shaped push arms bring the blade closer to the machine, providing excellent maneuverability, balance and blade penetration.
■ Blades feature a strong box section design, made from high tensile strength steel to stand up to the most severe applications.

Undercarriage

■ Undercarriage is provided by China industry expert ensures high reliability and resistance to wear.
■ Carrier rollers track rollers and idle rollers are all maintenance free.
■ Planetary final drive design delivers increased torque ratio for higher transmission effi ciency and lower maintenance cost.
■ Durable final drive bearings and multiple wet disc brakes provide reliability, reduce system heat and extend overall life.
■ Blades feature a strong box section design, made from high tensile strength steel to stand up to the most severe applications.


Ripper

Weichai Engine

Technical Parameters
Model
SEM816D
SEM816D LGP
SEM816FR
Operating Weight
16,900KG
19,490KG
18,580KG
Ground Pressure
66.8Kpa
31.1Kpa
66.9Kpa
Ground Clearance
410mm
410mm
410mm
Max.Slope
30°
30°
30°
Engine
WEICHAI Diesel Engine
Model
WD10G178E25
Rated Power
131KW
Working Tool
Blade Type
SU
S
LGP
SU Forestry
S Forestry
Blade Capacity
4.3m3
3.5m3
3.4m3
6m3
5.8m3
Blade Width
3,180mm
3,590mm
4,410mm
3,180mm
3,590mm
Blade Height
1,240mm
1,165mm
1,000mm
1,625mm
1,625mm
Max.Blade Digging Depth
430mm
430mm
470mm
430mm
430mm
Max.Blade Lift Ground Clearance
1,041mm
1,041mm
1,055mm
1,041mm
1,041mm
Max.Output Rimpull
280KN
Max.Digging Depth Of Ripper
584mm
/
584mm
584mm
Max.Clearance Under Tip
615mm
/
615mm
615mm
Powertrain
Type
Dual-path,closed loop electronically controlled hydrostatic drive system
Travel Speed-F/R
Infinitely variable speeds 0-10km/h
Steering & Brake
Hydrostatic steering;Wet,multi-disc brake
Min.Streeing Radius
3,610mm
3,740mm
3,610mm
Undercarriage
Track Shoe Width-Single
510mm
/
560mm
Track Shoe Width-APEX
/
1,050mm
/
Track Shoe Quantity
37
42
37
Length Of Track On Ground
2,430mm
2,925mm
2,430mm
Track Gauge
1,880mm
2,300mm
1,880mm
Track Roller Quantity
6
7
6
Carrier Roller Quantity
2
2
2
Hydraulic System
Type
Center colse,pilot control
Implement Hydraulic System Pressure
19Mpa
Service Refill Capacity
Fuel Tank
320L
320L
320L
Cooling System
45L
45L
45L
Engine Crankcase
24L
24L
24L
Final Drive(Each Side)
30L
30L
30L
Hydraulic Oil Tank
140L
140L
140L
Pivot Shaft Case(Each Side)
1.2L
1.2L
1.2L
Packing & Delivery
Packaging
Size
6600*3164*3076mm(Include the ripper)
Weight
17230 KG



Packaging Details


SEM816D
Type of shipping:RORO(Roll-On Roll-Off)
Port:Tianjin,Qingdao,Shanghai
Packaging
Size
5350*4410*3110mm
Weight
19,490KG
Packaging Details


SEM816DLGP
Type of Shipping:RORO(Roll-On Roll-Off)
Port:Tianjin,Qingdao,Shanghai
Our Service

Pre-Sales Service

* Inquiry and consulting support.

* View the Caterpillar-SEM Factory.

After-Sales Service

* We can supply the original parts of SEM factory

* Cat-SEM engineers available to service machinery overseas.
